1. Basic Parameter Table
| Parameter Category | Details |
|---|---|
| Power Range | 30W-300W (including 8 specifications: 30W, 50W, 80W, 100W, 150W, 200W, 250W, 300W) |
| Luminous Efficacy | 180-190lm/W (for 30°/60°/90°/T2M/T3M beam angles) 200-210lm/W (for 120° beam angle) 160-170lm/W (for 25°×75°/35°×75°/30°×105° beam angles) |
| Color Temperature Options | 3000K / 3500K / 4000K / 4500K / 5000K / 5700K / 6000K / RGB |
| Dimming Methods | Non-dimmable / 0~10V dimming / DALI / DMX512 |
| Protection Ratings | IP66 (waterproof and dustproof), IK08 (impact resistance) |
| Operating Environment | Temperature: -40℃~45℃; Humidity: 10%~90% |
| Quality Certifications | CE, RoHS |
| Warranty Period | 5 years |
